TriPod

[TomyJ]

Wiring

Battery Port is in,:clapping: I am not liking square holes from round holes. I am not a fan of wiring, Now to run it from the handlebars (Throttle, Key switch, Brake lever wires, Headlight) Into the headstock, where I hope to run the 3/4 plastic conduit with the battery leads to the swing arm wiring panel, :gah:



[Zammy]

I'm seeing a lot of progress Tomy, ThumbUp



[TomyJ]

OMG! ToWire

------:gah::xszpv:EDIT: Ordered another J-box, fuse block for the lights and 3/4 &1" grommets, And insulated line clamps...



[TomyJ]

Junction Box

Made the Alum frame for the J-Box with the fuse block inside (water proof) for the horn/ lights/flasher now need to drill wiring side holes, How can this little stuff take so damn long...:gah:



[Jack Klarich]

View attachment 100255Made the Alum frame for the J-Box with the fuse block inside (water proof) for the horn/ lights/flasher now need to drill wiring side holes, How can this little stuff take so damn long...:gah:

Attention to detail and getting it right



[TomyJ]

-Plastic snap in grommets to fuse block--Wire hole--HandleBar wires to bulkhead and fuse block, :clapping:



[Zammy]

Tom, one step at a time, you'll get it right and it's looking good.



[TomyJ]

More wires

-Handlebar wires, Throttle, key switch, Front brake light switch, Headlight, Horn. Some to be lengthened and some the connectors changed...:gah:



[TomyJ]

Wiring

Handlebar wiring, grommet hole in frame, -After their journey through the frame I tested each one before going further. Distant neighbor stopped by and said all my projects looked great and this eTrike is his favorite, he asked the price when finished so I told him $3K, and he said that was cheap with all the custom work !!! And he told his wife he wanted it and we'll talk later, YEA! :clapping:



[TomyJ]

J-Box3 wiring

J-Box3, 60 amp breaker and terminal bar wiring, finish soon, :gah:



[TomyJ]

J-Box3

--Mounting the J-Box3 with Main circuit breaker and Terminal bar inside and all is square to the swing arm, -:clapping:



[TomyJ]

Motor Location

Motor location and chain alignment Steel plate .312/.250, drawing to machinist for chain adjustment grooves, Ordered the master link, :Coffee:



[TomyJ]

Mock up

2021-07-20-2021-07-212021-07-23- J-Box covers are on, More mock up, and waiting for the master link...:clapping:



[TomyJ]

Master Link

Master Link and chain completed, Painting the tail light (LED) bracket that will bolt to the rear seat bottom--Even the lights have reflectors, And I think the rear reflectors are suppose to be red?epper:



[TomyJ]

HornTime

-Horn Time- This was suppose to be easy,:gah:



[TomyJ]

Damn Horn

Damn Horn,:gah: Will not work with metal bracket (second one) So I cut a piece fiberglass off the left overs from the fender and mounted the horn to it in the center, (works,:clapping So now to mount it up and wire it. epper:



[TomyJ]

Pedestal

Drawing and working on the pedestal mount for the 3 switches, 1.Forward-brake-Reverse. 2. Speed 1-2-3, 3. Lights-Brake lever and foot, Flashing- Tail- Headlight...EDIT:-:gah:



[TomyJ]

Directions

Hi guy's long time running, smashed my big toe really good 2 weeks on the sofa (drawings time) did not want to go through the process of Aluminum Rec tubing so I doug out the extra J-Box and mounted the forward-Reverse lever and the Speed 1-2-3 and for now I'll wait on the lights, just the horn and maybe the flashing tail lights. These projects are up for sale because the rents here are going crazy high so I'm going to try and buy one of those SmallHouses and add he-shed/carport? and rent space or buy?



[trikeman]

Glad you’re back. Good luck house shopping. :wave4:



[TomyJ]

Batt and wires

---I still hate wires, :gah:
